Key Features
    • Fixed back plate for added rigidity
    • Cutting edge is strategically positioned
    • Fixed tailgate helps in rough situations
    • Scarifier has three depth adjustments
View More Specs
John Deere BB20 Series
Features
Specifications
Brochure

Fixed back plate is heavy duty for added rigidity

Strong formed upper edge Strong formed upper edge
#

The heavy-duty concave back plate, with a formed upper edge, provides added rigidity and strength for trouble-free performance.

Cutting edge is strategically positioned for a fine finish

BB Series Box Blade cutting edge is reversible BB Series Box Blade cutting edge is reversible
#

The BB Series Box Blade cutting edge ensures precise leveling and a fine finish. It is also reversible for twice the wear life.

Fixed tailgate helps in rough situations

Model BB2048L shown Model BB2048L shown
#

The tailgates on the BB20 and BB20L Series Box Blades are fixed, giving the cutting edge extra power to slice through hard, compacted ground.

iMatch™ quick-hitch compatible for quick, efficient hookup

Innovative hitch system Innovative hitch system
#

The iMatch Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.

Scarifier has three depth adjustments for a variety of ground conditions

BB20 and BB21 Series scarifier BB20 and BB21 Series scarifier
#

Adjustments are easy on the BB20 and BB21 Series Box Blades. Simply remove the steel pin and raise or lower the scarifier to increase or decrease ground penetration.



Scarifier shanks can be stored on the scarifier beam when using a box blade for other tasks.

Working width 182.9 cm
72 in.
Unit height 85.1 cm
33.5 in.
Unit depth 78.7 cm
31 in.
Endplate thickness 1 cm
0.375 in.
Moldboard thickness 0.5 cm
0.1875 in.
Operating weight 242.2 kg
534 lb
Shipping 515.3 kg
1136 lb
PTO Horsepower 20.1-33.6 kW
27-45 hp
Compatibility Cat. 1
iMatch™ compatible (Cat. 1)
Quick coupler (Cat. 2)
Capacity 0.54 m3
19 cu ft
Design Reinforced with formed edge end plates
Reversible Yes
Quantity Two
Size 1.27×15.24 cm
0.5×6 in.
Shank type 3 position with holes
Points Replaceable
Quantity Six
Tubular scarifier beam size 4x4x0.25 in.
10.16×10.16×0.64 cm
Beam reinforcement bar size 0.95×2.54 cm
0.375×1 in.
Type Fixed
Type Bolt on
Color JD Green
Configuration Two units per crate
Labor hours 0.5
Time period 1 year
