New Equipment Implements and Attachments Land Planes John Deere LP21 Series

John Deere LP21 Series

NEW

John Deere LP21 Series

Local Pickup Only
John Deere Financial | Apply Today
Get A Quote
Key Features
    • Adjustable skid shoes
    • Scarifier shanks
    • Cutting edges are reversable and replaceable
    • iMatch™/Quick Hitch Compatible
View More Specs
John Deere LP21 Series
Features
Specifications

Adjustable skid shoes extend cutting edge life

Skid shoes are adjustable up and down Skid shoes are adjustable up and down

Skid shoes increase the life of the cutting edges on the land planes while avoiding damage to the working surface.



The skid shoes are adjustable up and down on each side plate to allow for the creation of a crown on a road for water runoff.



By replacing the skid shoes when needed, it will extend the life of the land plane.

Scarifier shanks in base for ripping up hard ground or aggressive grading

Adjustable for different types of groundwork scarifier shanks shown engaged Adjustable for different types of groundwork scarifier shanks shown engaged
Adjustable shanks Adjustable shanks

The scarifier shanks can be easily adjusted for depth control.

Working width LP2054L: 137.2 cm
54 in.
LP2160: 152.4 cm
60 in.
LP2172: 182.9 cm
72 in.
LP2184: 213.4 cm
84
LP2196: 243.8 cm
96
Overall Width LP2054L: 147.3 cm
58 in.
LP2160: 165.1 cm
65 in.
LP2172: 193.0 cm
76 in.
LP2184: 223.5 cm
88 in.
LP2196: 254.0 cm
100 in.
Overall Height LP2054L: 83.8 cm
33 in.
LP2160: 88.9 cm
35 in.
LP2172: 88.9 cm
LP2184: 88.9 cm
LP2196: 88.9 cm
Overall Length LP2054L: 121.9 cm
48 in.
LP2160: 121.9 cm
LP2172: 121.9 cm
LP2184: 137.2 cm
54 in.
LP2196: 137.2 cm
Height to Hitch Pins LP2054L: 35.6 cm
14 in.
LP2160: 40.6 cm
16 in.
LP2172: 40.6 cm
LP2184: 40.6 cm
LP2196: 40.6 cm
Operating LP2054L: 143.3 kg
316 lb
LP2160: 219.5 kg
484 lb
LP2172: 239.5 kg
528 lb
LP2184: 276.7 kg
610 lb
LP2196: 296.2 kg
653 lb
Shipping LP2054L: 308.4 kg
680 lb
LP2160: 461.8 kg
1018 lb
LP2172: 501.7 kg
1106 lb
LP2184: 553.4 kg
1220 lb
LP2196: 615.1 kg
1356 lb
Implement code
Required PTO horsepower LP2054L: 13.4-22.4 kW
18-30 hp
LP2160: 18.6-37.3 kW
25-50 hp
LP2172: 18.6-37.3 kW
LP2184: 29.8-67.1 kW
40-90 hp
LP2196: 29.8-67.1 kW
Style All:Clevis w/ Pin
3-point compatibility LP2054L: Cat 1 Limited
LP2160: Cat 1
LP2172: Cat 1
LP2184: Cat 1 and 2
LP2196: Cat 1 and 2
iMatch™ compatible (Cat. 1)
Quick-coupler compatible (Cat. 2) All:Yes
Pull-type
Type All:High Carbon Heat Treated Blades
Reversible All:Yes
Replaceable All:Yes
Quantity All:Two
Size, in. (cm) All:0.95×15.2 cm
0.375×6 in.
Placement All:Blades Positioned at a 10 Degree Angle
Configuration All: Infinitely adjustable
Thickness LP2054L: 0.635 cm
0.25 in.
LP2160: 0.95 cm
0.375 in.
LP2172: 0.95 cm
LP2184: 0.95 cm
LP2196: 0.95 cm
Height adjustment range All:6.35 cm
2.5 in.
Configuration All:One unit
Labor hours
Time period All:1 year
Adjustable LP2054L: 3 Position
LP2160: 4 Position
LP2172: 4 Position
LP2184: 4 Position
LP2196: 4 Position
Heat treated All:Yes
Available
Points
Quantity LP2054L: 4
LP2160: 4
LP2172: 5
LP2184: 6
LP2196: 7
Tubular scarifier beam size
Tubular scarifier beam thickness
Scarifier Depth Range LP2054L: 0 cm 0 in. , -3.81 cm -1.5 in., -7.62 cm -3 in.
LP2160: 5.08 cm 2 in. , 0 cm 0 in. , -5.08 cm -2 in. , -10.16cm -4 in.
LP2172: 5.08 cm 2 in. , 0 cm 0 in. , -5.08 cm -2 in. , -10.16cm -4 in.
LP2184: 5.08 cm 2 in. , 0 cm 0 in. , -5.08 cm -2 in. , -10.16cm -4 in.
LP2196: 5.08 cm 2 in. , 0 cm 0 in. , -5.08 cm -2 in. , -10.16cm -4 in.
