New Equipment Implements and Attachments Overseeders John Deere TR20 Series

John Deere TR20 Series

NEW

John Deere TR20 Series

Local Pickup Only
John Deere Financial | Apply Today
Get A Quote
Key Features
    • Straight blade aerator rotor aerates soil and incorporates seed in one step
    • Rear cultipacker levels and smooths seedbed
    • Front gauge roller levels ground, controls seed depth
    • iMatchTM compatible
View More Specs
John Deere TR20 Series
Features
Specifications
Brochure

Aerator rotor

Straight blades provide one-step dual functions Straight blades provide one-step dual functions

The TR2058 Overseeder has a straight blade aerator rotor that aerates the soil and incorporates the seed all in one step.

Rear cultipacker

Firms and smoothes the turf Firms and smoothes the turf

The TR2058 Overseeder has rear cultipacker rings that compact and level the turf to ensure successful germination.

Front gauge roller

Levels ground and controls seed depth Levels ground and controls seed depth

By adding the front gauge roller onto the TR2058 Overseeder, the operator can level the ground and control the seed depth. This is recommended for rental operations.



NOTE: Gauge wheels and the front roller cannot be used together.

Scraper bar

Optional scraper bar Optional scraper bar

The optional scraper bar on the TR2058 Overseeder is ideal for clay or wet conditions.

C-blade tiller

C-blade tiller creates versatility C-blade tiller creates versatility

By simply unbolting the double flanges at each end of the aeration rotor, operators can install the optional tiller rotor. This transforms the TR2058 Overseeder Aerator into a primary seedbed preparation machine.

Field-installed gauge wheel kit for TR2058 Overseeder

The field conversion gauge wheel kit for the TR2058 Overseeder includes two wheels and arms that can be set to ride on the wheels, so when lowered, they prevent the overseeder from lowering too far.

Front roller, tilling roller, and rear roller scraper field-conversion kits for TR2058 Overseeder

The first attachment is a field-installed front roller kit to compact soil for the aeration rotor.



The second attachment is a field-installed tilling roller kit to assist in preparing new seedbeds.



The third attachment is a rear roller scraper to keep material from kicking over the backside of the roller, leaving a smooth, finished job.

Working width 147 cm
58 in.
Overall width 168 cm
66 in.
Height
Shipping weight 539 kg
1188 lb
Operational weight 453 kg
998 lb
PTO hp 19-37 kW
25-50 hp
PTO rpm 540 rpm
Rotor rpm 231 rpm
Hopper 150 m3
4.26 bu
Quantity
Length
Quantity 18
Quantity 52
3-point type
iMatch™ compatible Yes
Labor hours 0.5 hours
Time period One year
Date collected
View Brochure
