New Equipment Implements and Attachments Rotary Tillers John Deere RT23 Series

John Deere RT23 Series

NEW

John Deere RT23 Series

Local Pickup Only
John Deere Financial | Apply Today
Get A Quote
Key Features
    • Heavy-duty wear shields for added gearcase protection
    • Hitch is Quick-Coupler compatible for easy hookup
    • Rotor is helical shaped for higher efficiency
    • Skid shoes control depth
View More Specs
John Deere RT23 Series
Features
Specifications
Brochure

Cage roller adjustment for firming action is easy

Ideal for controlling wind erosion Ideal for controlling wind erosion

The hand crank makes adjusting the depth of the roller easy on the RT22 and RT23 Series Rotary Tillers. Use a lower setting for more firming action, ideal for controlling wind erosion.



The RT22 and RT23 Series have an optional hydraulic cage roller adjustment kit available to allow for depth adjustments without leaving the tractor seat.

Heavy-duty wear shields for added gearcase protection

Wear shields protect gearcase Wear shields protect gearcase

The gearcase is protected from abrasion and premature wear by the heavy-duty wear shields.

Hitch is Quick-Coupler compatible for easy hookup

Hitch attachment is easy and fast Hitch attachment is easy and fast

Implement-to-tractor hookup is simple with the Quick-Coupler Category 2 compatibility.

Rotor is helical shaped for higher efficiency

Helical shape increases efficiency Helical shape increases efficiency

The helical-shaped rotor decreases horsepower required to drive units. They are designed so they enter the field at different times for more efficiency.

Skid shoes control depth

Skid shoe height adjusts easily Skid shoe height adjusts easily

Easily adjust the working depth by adjusting the height of the skids with the adjustment bracket.



If the rotary tiller is equipped with the optional cage roller, the unit will still be equipped with skid shoes for wear protection.

Rotor flange reinforcement kit

Rotor flange reinforcement kit Rotor flange reinforcement kit
#

The reinforcement kit helps to reduce blade damage around the bolt holes in rocky or hard soil conditions.

Working width 259.1 cm
102 in.
Outside to outside width 274.3 m
108 in.
Operating with skid shoes 893.6 kg
1,970 lb
Operating with cage roller 1,175.3 kg
2,591 lb
PTO speed rpm 540
Minimum horsepower 60 kW
80 hp
Maximum horsepower 97 kW
130 hp
Type Multi speed
Oil cooler
Type Gear Side Drive
Chain, ASAE
3-point compatible Cat II
iMatch™ compatible (Cat. 1)
Quick coupler (Cat. 2) Yes
Quick coupler (Cat. 3)
Adjustable offset
Clutch type Friction
Shape L-shape
Flanges (quantity) Eleven
Blades (quantity) Six
Type Skid shoes, optional Cage Roller
Maximum working depth 27 cm
10.6 in.
Rear door support Metal Rod w/ Double Spring
Parking stand Standard
Markings Standard
Type Heavy Duty
Labor hours
Time period 1 year
Date collected
View Brochure
