John Deere SB12 Series
Key Features
- Durable cutting edge
- Adjustable skid shoes
- Hydraulic chute deflector
- Field-installed cutting edge kits
John Deere SB12 Series
John Deere SB12 Series
Features
Specifications
Brochure
Cutting edge is durable for lasting performance
Durable cutting edge
Cost savings are realized because of the cutting edge’s long-lasting performance.
Blow snow anywhere with the hydraulic chute rotation
Allows operators to blow snow where they want
The hydraulic chute rotation adds versatility by allowing operators to blow snow exactly where they want.
Adjustable skid shoes extend life of cutting edge
Extend life of cutting edge
The adjustable skid shoes extend the life of the cutting edge.
Control the angle with the hydraulic chute deflector
Operator controls deflector angle
The hydraulic chute deflector allows operators to control the blowing angle.
| Height | 76.2 cm 30 in. |
|||
|---|---|---|---|---|
| Transport width | 204.5 cm 80.5 in. |
|||
| Working width | 203.2 cm 80 in. |
|||
| Length | 124.5 cm 49 in. |
| Operating | 406 kg 895 lb |
|||
|---|---|---|---|---|
| Shipping | 461.3 kg 1017 lb |
| Type | Three-part | |||
|---|---|---|---|---|
| Deflector adjustment | Standard Hydraulic |
|||
| Rotation type | Hydraulic | |||
| Diameter | 26.7 cm 10.5 in. |
|||
| Rotation degrees | 210 degree (angle) |
| Diameter | 50.8 cm 20 in. |
|||
|---|---|---|---|---|
| Speed | 170 rpm | |||
| Overload protection | Single |
| Blades | Four | |||
|---|---|---|---|---|
| Speed | 540 rpm | |||
| Diameter | 66 cm 26 in. |
|||
| Width | 26.7 cm 10.5 in. |
| PTO | 540 rpm | |||
|---|---|---|---|---|
| Minimum hp | 22.4 kW 30 hp |
|||
| Maximum hp | 60 hp 80 hp |
|||
| PTO overload protection | Shearbolt |
| Roller | 60 | |||
|---|---|---|---|---|
| Idler adjustment | Automatic |
| Compatibility | Cat. 1, 2 | |||
|---|---|---|---|---|
| iMatch | Yes | |||
| Quick coupler | Yes |
| Type | Replaceable |
|---|
| Type | Steel, adjustable |
|---|
| Labor hours | One hour |
|---|
| Machine | One year | |||
|---|---|---|---|---|
| Gear box | One year |
