New Equipment Compact Construction Equipment Compact Wheel Loaders 344 P-Tier Compact Wheel Loader

344 P-Tier Compact Wheel Loader

NEW

344 P-Tier Compact Wheel Loader

Local Pickup Only
0% for 36/mo | Apply Today
Get A Quote
Key Features
    • Net Power: 76 kW (103 hp) at 2,000 rpm
    • Operating Weight: 8860 kg (19,533 lb.)
    • Bucket Capacity: 1.5–2.0 m3 (2.0–2.6 cu. yd.)
View More Specs
344 P-Tier Compact Wheel Loader
Features
Specifications

Turn Things Around

  • Industry-exclusive Articulation Plus™ steering system combines 30 degrees of articulation with 10 additional degrees of rear-wheel steer. Reduced articulation angle design delivers tighter turns that are more stable, especially with large loads, than comparatively sized loaders without Articulation Plus.

On the Level

  • Loader arm and coupler design improves the lifting path to near parallel — for better load-carrying capability than previous models. This keeps the load more level from ground to truck-bed height and helps the operator focus on the task instead of on making manual adjustments.

Reach Your Goals

  • Outstanding reach enables the 344 P-Tier to efficiently dump to the center of tandem-axle trucks, for quick loading cycles. With exceptional lift and height to hinge pin, the optional High-Lift configuration makes this capable compact especially adept at repetitive dumping and stacking applications.

Fast Getaway

  • With a standard top speed of under 25 mph, the 344 P-Tier can make some pretty quick moves on and between jobsites.

Control and Command

  • Low-effort joystick controls boom and bucket, forward-neutral-reverse (F-N-R), and differential lock. Adjustable-height monitor lets operators keep close watch on vital machine functions.

Enjoy the Ride

  • Standard ride control cushions the boom during travel over rough and uneven terrain, reducing material spillage from the bucket and minimizing site cleanup.
Engine Manufacturer John Deere
Engine Model PowerTech PWS 4045H
Displacement, ltr (Inches³) 4.5 (275)
Rated Speed, rpm 2000
Engine Output – Net, kW (hp) 76 (103)
Torque, Nm (lbf / ft) 405 (299)
Transmission Type Hydrostatic
Front Differential Type Locking
Rear Differential Type Open
Tire size – Standard 17.5 R25
Service Brake – Type Wet Disc & Drum
Service Brake – Actuation Hydraulic
Parking Brake – Type Wet Disc
Height – Over Cab, mm (ft/in) 3030 (9 ft 11 in)
Wheelbase, mm (ft/in) 2600 (8 ft 6 in)
Ground clearance, mm (inches) 430 (16.9)
Width Over tires – Std, mm (ft/in) 2370 (7 ft 9 in)
Height – Pivot Pin, mm (ft/in) 3720 (12 ft 2 in)
Reach – At 2130mm 45° Dump, mm (ft/in) 1640 (5 ft 5 in)
Fuel Tank, ltr (gallons (US)) 155 (40.9)
Hydraulic Tank, ltr (gallons (US)) 115 (30.4)
Heaped Capacity, m³ (yd³) 1.5 (2)
Breakout – Bucket, kgf (lbf) 7443.9 (16411)
Ride Control System Yes
Pump Type Gear
Pump Flow – 1, lt/min (gallons (US) / min) 115 (30)
System Pressure, bar (PSI) 240 (3480)
Operating Weight, kg (lbs) 8860 (19533)
*Offer subject to change at any time. Financing requires approved credit with John Deere Financial, f.s.b. Down payment may be required. Prices and savings in U.S. dollars.

Additional attachments and options available in-store.

John Deere Rewards discounts can be applied to in-store purchases.

Finance calculator is for estimation only. Taxes, fees, set up and delivery may increase your monthly payment. Same-day pickup not guaranteed for equipment orders.

The engine horsepower and torque information are provided by the engine manufacturer to be used for comparison purposes only. Product features subject to change. Images of options may not accurately represent products purchased. Call your local TriGreen dealership for details.
