What Replaced the John Deere 1023E?
The John Deere 1E 23 is the direct replacement for the long-standing 1023E, maintaining the same proven performance while simplifying the platform and updating features for newer models.
If you’re searching for the 1023E, the 1E 23 is the closest equivalent available new today.
Want to test drive a 1 Series tractor?
1023E vs 1E 23: Quick Comparison
- Both tractors share 21.5 HP engines and identical PTO power
- Lift capacity remains the same at 758 lb
- Hydraulic performance is unchanged at 6.3 gpm total flow
- The 1E 23 features updated configuration and simplified feature set
Bottom line:
The 1E 23 replaces the 1023E with nearly identical performance, focusing on simplicity and consistency rather than major spec changes.
| Specification | 1023E | 1E 23 |
| Engine power | 21.5 hp | 21.5 hp |
| Power take-off (PTO) power | 12.1 kW 16.2 hp | 12.1 kW 16.2 hp |
| Lift capacity, 24-in. behind link arms | 344 kg 758 lb | 344 kg 758 lb |
| Cruise control | No | No |
| Approximate shipping weight | 1446 lb | 1446 lb |
| Wheelbase | 57.1 in. | 57.1 in. |
| Engine Manufacturer | Yanmar® | Yanmar® |
| Rated engine speed | 3200 rpm | 3200 rpm |
| Power take-off (PTO) power | 12.1 kW 16.2 hp | 12.1 kW 16.2 hp |
| Brakes | Wet disc (left-hand pedal) | Wet disc (left-hand pedal) |
| Steering | Power | Power |
| Hydraulic type | Open center | Open center |
| Remote control valves available | Three | Three |
| Turning radius without brakes | 8.2 ft | 7.61 ft |
| Backhoe | No | Optional |
| Cab | No | No |
| Warranty | 6-year / 2,000 powertrain 10 Year TriGreen Secure Warranty | 6-year / 2,000 powertrain 10 Year TriGreen Secure Warranty |
1023E vs 1E 23 Pricing
Pricing depends heavily on attachments and configuration, but generally:
1023E (legacy inventory)
- May be available at discounted pricing at your local TriGreen – ask about 1023Es that qualify for special Orange Tag savings!
- Good value option for budget-conscious buyers
1E 23 (new model)
- Positioned as the current entry-level 1 Series tractor
- Pricing varies based on:
- Loader packages
- Mower decks
- Attachments
For accurate pricing, build your own configuration:
What Can the 1023E and 1E 23 Do?
Both models are ideal for:
Residential property maintenance
- Mowing small to medium acreage with the belly mower
- Yard grading and leveling
- Bush hogging taller weeds and grass
Light loader work
- Moving mulch and dirt
- Light material handling
Should You Choose the 1023E or 1E 23?
Choose the 1023E if:
- You find a great deal on remaining inventory
- You don’t need the newest model
- You want proven performance at a lower price
Choose the 1E 23 if:
- You want the current production model replacing the 1023E
- You want a factory-installed backhoe at an affordable price
- You’re buying new with long-term ownership in mind
FAQ: 1023E vs 1E 23
What replaced the John Deere 1023E?
The 1E 23 directly replaces the 1023E, offering the same performance in a simplified platform.
Is the 1E 23 more powerful than the 1023E?
No—both tractors produce 21.5 horsepower and have identical PTO and hydraulic performance.
Are attachments compatible between the 1023E and 1E 23?
Yes—both tractors are compatible with many Category 1 implements and attachments.
